the principal unit stresses, Pi and p2. If pi and p2 were known, and p and p were then to be foundfrom the former, ,the construction shown in Fig. 67 would bemade, in which O M = 0 M = i(^i+^2) and MR = MR= 2(Pi~p2)- If one of these normals were revolved around Oto coincide with the other, the… … Fig. 67 normal to that plane, and O R the unit stress p in magnitudeand actual direction of action on A B. OR represents eithertension or compression, as the case may be. Now let the planeon which p acts, together with its normal and p itself in its relativeposition, be revolved about O until it…
