Surveying, with sections on map reading. military sketching and topographic drawing (1919)
United States. War dept. Committee on education and special training. [from old catalog] · Washington · leaf 58
try taking its combat train and store wagons. Thedistance is 1,000 yards. The combat train and store wagons are thento go 500 yards to the left, and stop in the shelter of the trees; thebattery is to go 200 yards to the right, and occupy positions on thereverse slope; the battery detail to ride 200… … WAR DEPARTMENT surveying COMMITTEE ON EDUCATION JOB No. 12 AND SPECIAL TRAINING PAGE i MAP READING Job No. 12 Construct a Degree Protractor; a Mil Protractor Equipment.—Drawing paper, 4-H pencil, 45-degree triangle, 60-degreetriangle, rule with inches divided into tenths, smooth white cardboard…
Surveying · Military topography · Topographical drawing
