Tappet and dobby looms : their mechanism and management (1912)
Roberts, Thomas · Manchester [Greater Manchester] : Emmott & Co., Ltd. · leaf 197
Fig. 54. 186 TAPPET AND DOBBY LOOMS and the worm to the shaft C by means of the knob F, asshown in the sectional drawing in Fig. 56. Fitted to theend of the shaft is a short arm G; this is bored to receivethe pin H, which forms part of the knob. The face of thehand-wheel is provided with a series… … Fig. 55- and the worm must travel with the shaft C, this beingdriven by a train of wheels as follows: To the end of theshaft the spur-wheel K is secured, this being geared withthe pinion wheel L compounded with the change-wheelM; the change-wheel is geared into the star-wheel pinionN, which is…
