Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving (1888)
Posselt, Emanuel Anthony, 1858- · Philadelphia, Pub. by the author [etc.]; London, S. Low, Marston, Searle & Rivington, limited · leaf 186
Fig. 822. Fig. 821. Each wire a thereupon enters beneath a number of warp-threads and raises themslightly above the plane of the fabric. A shuttle is then shot through, after which the body-warp 4 rises and the pile-warp 1 descends, as shown in Diagram II of Fig. 822. The pile-warp 2 rises and a…
Textile design · Textile fabrics
