Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving (1888)
Posselt, Emanuel Anthony, 1858- · Philadelphia, Pub. by the author [etc.]; London, S. Low, Marston, Searle & Rivington, limited · leaf 210
Fig. S70. The method of operation and principle of construction of the cutting-device is illustrated bydrawings Figs. 865 to 873 inclusive. By means of the double cam C, operating the rack-bar and cog-gearing, alternate partialrevolutions in each direction are given to the pulley-wheel F, to which…
Textile design · Textile fabrics
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
