Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving. Containing also an appendix showing the analysis and giving the calculations necessary for the manufacture of the various textile fabrics (1889)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Pub. by the author [etc.]; London, S. Low, Marston, Searle & Rivington, limited · leaf 208

An illustration from Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving. Containing also an appendix showing the analysis and giving the calculations necessary for the manufacture of the various textile fabrics, 1889, leaf 208 — J* 1^ Fig. 869. … Fig. 870. The method of operation and principle of construction of the cutting-device is illustrated bydrawings Figs. 865 to 873 inclusive. By means of the double cam C, operating the rack-bar and cog-gearing, alternate partialrevolutions in each direction are given to the pulley-wheel F, to which…

Textile fabrics

Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
