Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving (1888)
Posselt, Emanuel Anthony, 1858- · Philadelphia, Pub. by the author [etc.]; London, S. Low, Marston, Searle & Rivington, limited · leaf 252
OF^ Jam … Fig. 989a. Fig. 9895. Referring to letters of reference: A A are the side frames of the loom, B is the main shaftand Cthe crank-shaft, D is the lathe, a is the breastbeam and b the cloth-roller, E is the warp-beam, e the warp-threads. On the two upright extensions F of the side frames is a…
Textile design · Textile fabrics
