Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving (1888)
Posselt, Emanuel Anthony, 1858- · Philadelphia, Pub. by the author [etc.]; London, S. Low, Marston, Searle & Rivington, limited · leaf 257
he cards. 10. The Jacquard harness. In Fig. 999 we give a clear understanding of the principle of the construction of a Jacquardmachine by means of the sectional cut of one cross row in a 200 Jacquard machine, containing8 hooks, (representing an 8-row-deep machine), illustrating by it the… … 251 hooks are held in their required places by the eyes of the needles (see place v at hook i) throughwhich the former are passed. The needles rest with their heads a to b, in the needle-board, extending outside, towards thecylinder, for about y2 inch. The rear part of the needle—the loop—is passed…
Textile design · Textile fabrics
