Technology of textile design : a practical treatise on the construction and application of weaves for all textile fabrics and the analysis of cloth : containing also an appendix describing all the latest methods and improvements in designing and manufacturing : for the use of students, operatives, overseers, designers, mill managers, commission merchants and manufacturers (1905)
Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia : E.A. Posselt ; London : Sampson Low, Marston, and Co., Ltd. · leaf 193
re to be removed. The brake mechanism of the uncoiling fliers is constructed as follows : Upon the top of each sleeve there is pivoted upon one side a lever, through the centre of which there is a vertical hole coinciding with the opening of the stem. This lever has at its rear end a cam-surface,… … Fig. 827. Fig. 828. and thence rises to the eye i, mounted upon the top of the flier. So long as the portion of the thread between the eye and the axis of rotation of the fliers is substantially horizontal the lever will remain in a horizontal position ; but if that portion of the thread rises to…
Textile design · Textile industry · Weaving
Internet Archive · Getty Research Institute · Public domain (published before 1931). Free to use for anything.
