rt of the frame, as built in addition to hisregular cam loom for operating the harness. The beams carrying the pile warps rest in theupper middle part of said frame. To give a clearer understanding diagram Fig. 882 has beendesigned. In this A indicates the side of the frame previously alluded to, B… … Fig. 882. rollers H G, and from there to the respective harness, one great advantage over that of the pre-viously shown methods will be readily noticed, i. e., that the pile warps are delivered to their. respective heddles without crossing the ground system, and consequently any possible chafing…
