Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving. Containing also an appendix showing the analysis and giving the calculations necessary for the manufacture of the various textile fabrics (1889)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Pub. by the author [etc.]; London, S. Low, Marston, Searle & Rivington, limited · leaf 220

An illustration from Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving. Containing also an appendix showing the analysis and giving the calculations necessary for the manufacture of the various textile fabrics, 1889, leaf 220 — At the point indicated by A, one vertical row of one set of needles is shown (E — needleboard, B = spring box). At B one vertical row of the second set of needles is shown {C =needle board, P = spring box). a represents sections of stationary griffe-bars (shown shaded); <^ represents sections…

Textile fabrics

Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
