Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing (1890)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, S. Low, Marston · leaf 232

An illustration from Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing, 1890, leaf 232
hrow the shaft A full back, and this produces an extremelylong terry-loop. By this means a terry-loop of any desired length can be produced. When it is desired to throw the terry devices out of operation and to weave a plain fabric,the lever S, connecting with the lug /, as shown in Fig. 902, is…

Textile fabrics
