A text book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained (1849)

Minifie, William, 1805-1880 · Baltimore, W. Minifie & co. · leaf 107

An illustration from A text book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained, 1849, leaf 107 — Fiij.:?. … Tf^^-mm* PLATE XXIII. 53 from the points of division^ draw lines parallel to A. C, meetingD. 0 in 1, 2, 3, &c. 3rd. With an opening of the dividers equal to one of the divi-sions on D. Cy step off from D toward H, the same number ofparts as D. C is divided into^ making the right line D. H,…

Mechanical drawing · Geometry, Descriptive · Perspective

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
