A text book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained (1849)

Minifie, William, 1805-1880 · Baltimore, W. Minifie & co. · leaf 156

An illustration from A text book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained, 1849, leaf 156 — F/q.J. End view … ////. /.\r///(>// f/iionif/i //./////// //(//e.l/i 75 PLATES XXXVI AND XXXVII. PLAN, SECTIONS AND END ELEVATION OF A CYLINDER FOR A LOCOMOTIVE ENGINE. Fig. 1. Top view or Plan. Fig. 2. Longitudinal Section through Jl, By fig. 1, Fig. 3. Elevation of the end B^ fig. 1. Fig. 4. Transverse Section…

Mechanical drawing · Geometry, Descriptive · Perspective

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
