FIGURE 51. mark (No. 3 in Fig. 51) is just in line with the edge ofthe left field. The red lead will then be in positionshown in Fig 51, and the armature is in proper posi-tion to set the commutator. In the case of the right-hand drum armature heleading wire of the first coil should be found. This… … FIGURE 52. the outer coil, on the commutator end. With thiswire turned underneath, rotate the armature forward,or counter-clockwise, until the pegs on the right-hand
