A text book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained (1849)

Minifie, William, 1805-1880 · Baltimore, W. Minifie & co. · leaf 83

An illustration from A text book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained, 1849, leaf 83 — WMinin, Plate 17. SURFACES OF SOLIDS. FiQl. … 41 PLATE XVII. COVERINGS OF SOLIDS Fig. 1. The Sphere Is a solid figure presenting a circular appearance when viewed inany direction; its surface is every where equidistant from a pointwithin^ called its centre. 1st, It may be formed by the revolution of a semicircle around itschord. 2nd. The chord…

Mechanical drawing · Geometry, Descriptive · Perspective

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
