A text-book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained .. (1850)

Minifie, William, 1805-1880. [from old catalog] · Baltimore, W. Minifie & co. · leaf 97

An illustration from A text-book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained .., 1850, leaf 97
oblem 50. Fig. 1. To find Points in the Curve of an Ellipsis by Intersecting Lines. Let A. By be the given transverse axis, and C. Dy the conjugate.1st. Describe the parallelogram L. M, JV. 0, the boundaries passing through the ends of the axes.2nd. Divide A. L,—A. JY,—B. My and B. Oy into any…

Mechanical drawing · Geometry, Descriptive · Perspective
