Fig 931.—Magnetic field witharmature at rest. FIG. 932. -Magnetic field when currentflows in armature. in the armature, however, it produces a component of the magneticfield, perpendicular to that of the field magnets, and the resultantfield is as shown in Fig. 932. The brushes must now be placed…
