A practical treatise on weaving and designing of textile fabrics : with chapters on the principles of construction of the loom, calculations and colour (1879)

Ashenhurst, Thos. R. (Thomas R.) · Bradford : T. Brear ; London : Simpkin, Marshal · leaf 99

An illustration from A practical treatise on weaving and designing of textile fabrics : with chapters on the principles of construction of the loom, calculations and colour, 1879, leaf 99
mooth and easy. Then, to ascertain the nature ofthis action, we must consider first of all the direction ofapplication of the force and the magnitude of such force. 94 WEAVING AND DESIGNING First, as to the direction. This is determined by thepoint of contact of the picking tappet with the… … Fig;. 21. C the picking tappet. The cone being circular, if a line bedrawn tangent to the circle at the point of contact withthe tappet, as the tappet revolves the direction of forcewill be at right angles to this tangent, the line a will thenindicate the direction of the force. Then it must be OF…

Textile fabrics · Textile design · Weaving

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
