A text book of physics, for the use of students of science and engineering (1918)
Duncan, John, d. 1941, Starling, Sydney George, 1873- · London Macmillan · leaf 547
Fig. 476.—Indicator diagram showing the cycle in a gas engine. the pressure may be from 50 to 200 lb. wt. per square inch abovethat of the atmosphere, depending on the type of engine. 3 is theexplosion and expansion stroke. 4 is the exhaust stroke, duringwhich the pressure rises slightly above that… … FIG. 477.—Outline diagram of a gas engine. the connecting rod D. The cylinder is open at the end facing thecrank, and there is no piston rod. The cycle takes place on theleft-hand side of the piston only, and the right-hand side of thepiston is constantly exposed to the pressure of the atmosphere.…
Physics
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
