§15 PRACTICAL PROJECTION 99 PROBLEM 27 100. To i>roject views of a sphere intei*sected bya cylinder. When the position of these two solids is such that the axisof the cylinder passes through the center of the sphere, asshown in perspective in Fig. 55, the line of intersectionis shown in a right…
