in the chord BF,while the vertical component causes stresses in the webbing.For example, let the truss in the figure have a span of 50 feetand a depth of 6 feet, and let />V/ be inclined at an angle of 45degrees. Let the dead load per linear foot per truss be 400pounds, all taken on the upper…
