The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)

Murphy, William S · London : The Gresham Publishing Company · leaf 219

An illustration from The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing, 1910, leaf 219
ciency. So with theloom. All the parts had been developed, and the skill of the expertmachine builder alone was required to put them together into unity. 172 WEAVING With the keen insight of genius, Roberts selected from the numerousappHances which had then been devised the fittest for each… … Fig. 252.—Sharp and Robertss Power Loom A, Warp beam, b, Warp roller, c, Body of slay or lay. D, Breast beam. E, Cloth beam. F, F, Heddles.G, G, Heddle levers. H, H, Circular tappet wheels. i, i, Bowls of heddle levers. j, Sword of lay.K, Picker arm. L, End of shuttle in box. m, Reed or sley. N,…

Textile industry · Textile fabrics

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
