The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 136
for the hopper at the end of the slide remote from thecloth. Some of the other plush-pile appliances are lighter and less complexthan the high-wire apparatus, and rather more suitable for the lighterfabrics. A favourite is the Moxon type, of which Halls improvedwire-inserting motion (figs. 312 «,… … II III 312 c.—Plan of Halls Wire-Inserting Motion gear. The rope has a windlass motion on the large wheel, which isdriven by a tappet and gearing behind, controlled by the sheddingmotions of the loom. From the diagrams, the movements of thedriving and wire-inserting mechanisms can be easily…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
