The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 186
r a driven wheel be found in the train whichcan be changed. To increase the rate a driving wheel is enlarged,or the number of teeth on it increased, and for the same purpose thedriven wheel is reduced in size, or the number of its teeth decreased.We may plan to change either a driving or a driven… … Fig. 344.—Change-wheel Setting-up Motion A, Driving pawl. B, Lever. c, Ratchet wheel. D, Change wheel.E, Cloth beam wheel. F, Intermediate. G, Pinion. H, Holding-up pawl.I, Spring catch. 156 WEAVING wheels together, and the known drivers, together with the circum-ference of the friction roller and…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
