The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 215
crank carriesthe inclined plate z. The jaws, e, f, are faced with velvet or some other suitablematerial. Each time the pin y passes over z the jaws are thereby opened to receivethe weft, and they close down on it by the action of a spring. In figs. 4 and 5 the weft holder is omitted for the sake of… … fc—/-f-lf. MODEL OF OPEN-SHED DOBBY LOOM Directions for Erecting Model of Loom.—Lift the two sides of the loom into an erect position.Bring the breast beam (38) up to a level with the starting handle (51) and insert white tabs into openings onboth sides. The going part, containing shuttle race…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
