The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)

Murphy, William S · London : The Gresham Publishing Company · leaf 55

An illustration from The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing, 1910, leaf 55
so much inshape and important details thatit is rather difficult to make onestand for the class without omittingessential features. Probably thebest plan is to take the very simplest form first, and then go on tostudy the particulars of one among the newest and best, without, how-ever, specifying… … Fig. 276.—Keighley Dobby: Driving Mechanism A, Compound pinion on crank shaft. B, Wheel on endof lag cylinder, c, D, Pin-wheels actuating B in oppositedirections, e, Reversing lever. F, Elbow-lever drivingthe lifting bars or knives shown in section at G, G. H, H,The grooves in which the knives…

Textile industry · Textile fabrics

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
