to lift the heald shafts. Various Dobbies.—As we have already stated, there are numerousdobby machines of various form and application. In all, however,the essentials are similar. Hooks and lifting bars or griffes, cylinderswith cards or lags, needles or pegs media between cylinder and… … rig. 280.—Jacquaid Dobby: the Needlesand Hooks A, Cylinder. B, Needle, c, Cards, d,Hook. E, Griffe. g, h, Bearings of theneedle. i, Spring. k, Slide for lifting ordepressing the needle plate to the level ofthe upper or lower row of holes in the cylin-der. L, Handle held in position by one orother…
