The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 222
MACHINE-MADE TUFTED CARPETS 173 motion of the common loom. With the ground and small chain thecase is opposite. Various motions have been invented to regulatethese tensions. The aim of every motion is to release the warp suffi-ciently for the shedding and wefting, and to tighten it up for the… … ^M^ Fig. 472.—Weft Needle of Axminster Carpet Loom A, Needle, b, Weft, c. Weft bobbin, d, Guidering. E, Tension bar. F, Ring eye on the rockinglever G which is pivoted on a stud H. G is fittedwith a spring i, which takes up any slack in the weft.J is the fell of the carpet. k, Vertical pin…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
