the rockinglever G which is pivoted on a stud H. G is fittedwith a spring i, which takes up any slack in the weft.J is the fell of the carpet. k, Vertical pin holdingthe edge of the fell pending beating up by the slay.L, Shuttle driven by a propeller m and carrying athread n through the loop in the… … Fig. 473.—Picking Mechanism of Axminster CarpetLoom A, Tappet shaft on which is a sleeve B flanged at Cand D. To these flanges tappets e and F are secured.G, H, Anti-friction rollers attached to treadles whichcarry on their ends the sockets l j, communicating byuniversal joints motion to the lever…
