1^.105. … Draw a line CD (Fig. 104) parallel to the weight force, that is,vertical, and make it equal to the weight, on a suitable scale.From C draw CE parallel to AC, and from D draw DE parallelto BC, thus completing the triangle CDE. As the weight hangsdownwards the sense of direction will be downwards ;…
