Taggart, William Scott · London : George Routledge & Sons, Ltd. · leaf 88
fi^AU Fi<^U5 point at C, on the paper beneath, where the three cords meet,and also a mark along each cord some little distance from C,and remove the paper. If lines are drawn through the marksthat have been made a force position diagram is obtained, as inFig. 115, and from this the triangle of… … fif.ll6. f^^ux^ Fi<s.m. The same apparatus may be used for more than three forces.For instance, in Fig. 116 there are six cords attached to a small 78 TEXTILE MECHANICS ring C Two of the cords are attached to springs, whilst theother four cords are weighted, three of which pass over smallguide…
Textile machinery
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
