Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools (1901)

Zipser, Julius, Salter, Charles · London : Scott, Greenwood · leaf 278

An illustration from Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools, 1901, leaf 278
,as shown, which is then grasped by the deliv-ery rollers j^, 5,and let fall into the can, r. Occasionally, as shown in Fig. 157, the tow slivers, a\ ir, cr\are simply united on a plate, h, to a single band, wliich is thenled awa\- bv the deliverv rollers, c, d, into the can, e. TEXTILE RAW… … Fig. 158.—Bell Signal on Tow Card. length of sliver. The mechanism (Fig. 158) is identical inprinciple with that already described, and the same lettersare used to denote the same parts in each case, so that thedescription already given will serve for both. 3. Drawing and Doubling. The machinery…
