Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools (1901)
Zipser, Julius, Salter, Charles · London : Scott, Greenwood · leaf 305
Fig. 180. —Korting Injector (longitudinal section). All the tanks are fitted with a perforated false bottom, /,which can be removed in sections. The actual bottom, m, ineach case slopes downwards to the centre, thus enabling thedeposited dirt to accumulate in a receiver, n, whence it can beremoved… … Fig. 181.—Korting Injector (elevation). The tanks are connected by injectors or pumps, whichconvey the scour from one to the other in the shortest possibletime. A simple form of Korting injector is shown in Figs.180 and 181, the working of which is sufficiently indicated bythe arrows. TEXTILE RAW…
Textile fibers · Spinning
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
