Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools (1901)
Zipser, Julius, Salter, Charles · London : Scott, Greenwood · leaf 37
6, attached to the under side of two leather 30 TEXTILE RAW MATERIALS. belts, c, the whole constituting a set which is actuated by tv\ opulleys, d and e. A tress of flax,/, prepared by hand hack-ling is fixed in the clutch, g, so that the greater portion hangsdown free. The clutch is then placed on… … Fig. i5.—Powcr-hackling Machine (section). out of the hackles, leaxing the tow behind. Each time theclutch, g, is lifted it moves forward along the rail a distanceequal to the width of a set of hackles, and when the clutchdescends again the flax is acted upon by the next adjoiningset, which is…
Textile fibers · Spinning
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
