Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools (1901)

Zipser, Julius, Salter, Charles · London : Scott, Greenwood · leaf 487

An illustration from Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools, 1901, leaf 487
-hand after reeling, and defective portions are excised ; but thebetter class yarns are put through a gauging machine, whichenables the attendant to sort out unduly thick and otherwisedefective parts. A double machine for this purpose is shownin Fig. 299. Here the thread, c, from the bobbin, b,… … [izii^^^Qj Figs. 301-302 -Details of the Thread Gauging Machine (vertical sectionand view from above). slit,/, in the steel plate, g (see Figs 301-302), and between the-edge, g^, of this plate and the lever, i (which pivots at h),passing thence over the two glass rods, k, I, and turning down-wards…

Textile fibers · Spinning

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
