WEAVINCj 23 has been defined as a mechanism which aflfects thefollowing necessary movements: I. The lifting- of the healds to form an opening, Definition. , , , , , of a Loom or shed, or race for the shuttle to pass through. … DIAGRAM OF A HAND LOOM^—Warp Beam; 5—Cloth Beam; /7Z?—Lees Rods; //—Harness,r—Treddle. 2. The throwing of the weft or filling by meansof a shuttle. 3. The beating up of the weft left in the shed bythe shuttle to the cloth already formed. This threadmay be adjusted by means of the batten, needle,…
