Textile texts for cotton manufacturers : concerning the proper methods of equipping and running mills ... and a full list of the patented cotton machinery introduced and sold by the Draper Company (1903)

Draper, George Otis, 1867-1923 · Hopedale, Mass. : Draper · leaf 239

An illustration from Textile texts for cotton manufacturers : concerning the proper methods of equipping and running mills ... and a full list of the patented cotton machinery introduced and sold by the Draper Company, 1903, leaf 239
216 TWISTING. Spindleretainer … TWISraR SPIXDLE PARTS Blade. 8. Whorl. 9.Oil retainer underneath 10. whorl. 11.Bolster. Packing. 12. Packing strings. 13.Spring. Step. Base. Spindle retainer. Pin to hold on spindle retainer. Washer.Xiit. TWISTING. 217 Coiniiion on the smaller type, as the pins which locked the stepand bolster were…
