Thermodynamics of the steam-engine and other heat-engines (1907)
Peabody, Cecil H. (Cecil Hobart), 1855-1934 · New York, J. Wiley & sons; [etc., etc.] · leaf 457
ialdevice for making a vacuum to draw water from a reservoirbelow the injector, which will be described later. To start the injector shown by Fig. 91, the steam-valve is firstopened slightly to blow out any water that may have gatheredabove the valve, through the overflow, since it is essential to… … Fig. 91. Steam-valve is opened wide, and the jet of steam from the steam-nozzle mingles with and is condensed by the water and impartsto it a high velocity, so that it passes across the overflow spacebetween the combining-tube and the delivery-tube and passesinto the boiler. When the injector is…
Thermodynamics · Steam-engines · Heat-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
