A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 141

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 141
t 12to turn said ratchet and the gear 13. The pull pawl17 is made to engage, with Its free end, the auxiliaryratchet 14 in order to turn said ratchet and thegear 15. 140 A lever IS is centrally pivoted at 19 and has theupwardly curved extensions IS and IS. The exten-sion IS extends under a pin 16… … The lever 21, centrally pivoted at 22, has one end21 bent to extend under the pin 16 on the pawl 16.The lever 23, pivoted at one end on a stud 24, has atits other end a curved extension 23, which extendsunder the bent end of the pin 17 on the pawl 17. Thelevers 21 and 23 are connected by an…

Textile fabrics · Textile industry · Textile machinery
