A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 146

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 146
repeated instead of the chain being re-versed. Mlicn lu iiniUiplii a gireii pick, a roller 21 is broughtunder the end of lever 24 and it will raise saidlever and lower the end 2S, extending under the pawl11, to allow the extension 11 on the pawl 11 toengage with the ratchet wheel IS, connected… … a stud 7 being also secured in said plate 3. On thestud 5 is pivotally mounted the pull pawl S, and onthe stud G the push pawl 9, and on the stud.7 pullpawls 10 and 11 as working the multiplier. Faston shaft 12 is the drop box pattern chain cylinder13. Two ratchet wheels 15 and IC are fast on…

Textile fabrics · Textile industry · Textile machinery
