A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 147

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 147
oth jh!> nearestthe m u t i 1 atedgear ni3 is re-tracted, so thatsaid gear willnot rotate thegearwi. Now, ifit is desired tooperate the boxmotion, a ballon the patternchain raises thepattern leverand throughwire f/2 swingsthe controller tothe left and intodotted line posi-tion, the weightof the… … 147 gear iia will be rotated one-half revolution, caus-ing the stud Hi to travel in a circular path inthe recess da from above the axial centre of thegear »ii to directly below it, and out of the innerend of the groove d*, the gears nn and ni3 being outof mesh. If the box motion is to be again…

Textile fabrics · Textile industry · Textile machinery
