A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 149

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 149
central slot 4. Abolster plate 5 is secured to the lug 3 by the bolts6, extending through elongated holes in the lug 3,said bolster having a concave bearing on its upperend, on which bears the segmental cam 7 of thelever 8. In the centre of the cam 7, and nearone side of the cam. are two concave… … 9 is in the centre of the cam, the hooked arms 12are supported on what may be termed a deadbearing, because no strain exerted by journal 1on the hooked bars can change the position of thebearing. When the warp beam is to be removed, the leverS is swung into the position indicated in brokenlines,…

Textile fabrics · Textile industry · Textile machinery
