A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 157

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 157
g the running of the loom with or without itsfilling supplying mechanism. The illustration is a top plan view of the fillingfork slide and its co-operating parts of the fillingsupplying mechanism, the shipper lever being in in-operative position. On the filling fork slide is pivoted the usual… … tion. This lever 3 is provided with a cam surface 3,adapted to be engaged by the shipper handle. Thefree end of the lever 3 engages the arm 4 of an anglelever 4, the other arm of said angle lever being bentupward to engage the actuating lever 1 of the fillingsupplying mechanism. When the shipper…

Textile fabrics · Textile industry · Textile machinery
