A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 213

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 213
F thatwhen thepawl Hengages adeep toothe, it willalso en-gage a tooth of the ratchet F and will move bothratchets, but when it engages a shallow tooth e- it will 212 … not engage the tooth of the ratchet F, and conse-quently will move the ratchet E only. The pawl Htherefore moves the ratchet E twice as fast as itmoves the ratchet F. G is a gear wheel, journaled onthe shaft d, between the fast ratchet E and the looseratchet F, to the latter of which it is secured…

Textile fabrics · Textile industry · Textile machinery
