A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 233

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 233
indicatedby 4, the landing burr by r>. presser wheel by 6, andcast off burr by 7, the combined action of which per-forms the knitting operation in the usual manner. The atripinp iirraugcmrut consists of a pattern wheel8 which is provided with rows of holes for the inser-tion of screws, as at a,… … A-J 9 /o;, of said pattern wheel. Lever 11 is connected at itslower end to a horizontal rod (not shown), the otherend of which is connected to the lower end of a lever12 as pivoted at 13, the top end of said lever carryingan elbow lever 14 one end 15 of which carries a yarnfinger 16 and the other…

Textile fabrics · Textile industry · Textile machinery

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
