Fig. 47. MASONRY. 63 I beams /;, which carry the stone flag- or concrete pavement,shown at c. The space between the I beams is filled bythe fireproof blocks d. The curb stone is shown at c; when … bluestone or granite flags are used, they are usually carriedovit to the gutter line and project over the curb stone, or, ifsufficiently thick, the curb stone is omitted. The wallbetween the columns is indicated at/, and ^ is the concretebase on which the columns rest. 64 MASONRY. § 7 119. Another…
