13 feet wide, with 72 buckets,1 foot 6 inches deep, and an opening of 7 inches for theentrance of the water into the bucket. The internal segment,a, fig. 302, 28 feet 2^ inches diameter, 324 cogs, 3:|-inch pitch,and 14 inches wide on the cog, drives the pinion, 6, 5 feetdiameter, and gives motion… … SYSTEM OF GEARING. 185 wheel, c, from which the motion is conveyed to the mill bythe vertical shaft d, and the shaft /, driving the gig and stockshafts h and g. From this arrangement of the first motion wheels, it will be Fig. 302.
