Treatise on the steam engine (1839)

Renwick, James, 1790?-1863 · New-York, Carvill & Co. · leaf 153

An illustration from Treatise on the steam engine, 1839, leaf 153
in such a manner as toopen upwards, two shutters that fill up the rest of the circularopening of the piston. These shutters, therefore, rise and falltogether like wings, whence their name. The piston and itsvalves are usually called the Bucket of the Air-pump. Fromthe dimensions we have stated…

Steam-engines
