upper platecan be turned freely about their common centre. Thisplate carries a telescope Q, resting on two upright supportsKK, upon which it is movable in a vertical plane. Thetelescope, having thus a horizontal and a vertical motion, * The author is indebted to Professor Gillespies Treatise on… … Sec. V.] INSTRUMENTS AND FIELD OPERATIONS. 85 THE THEODOLITE. Fig. 52.
